Proto TorquePlus J7216H Standard Length Socket, Imperial, 3/8 in Square Drive, 1/2 in

Product Line: Proto
MFG #: J7216H
Proto TorquePlus J7216H Standard Length Socket, Imperial, 3/8 in Square Drive, 1/2 in

Your Price

$5.97 / EA

Proto TorquePlus J7216H Standard Length Socket, Imperial, 3/8 in Square Drive, 1/2 in

Product Line: Proto
MFG #: J7216H

Your Price

$5.97 / EA

Details

Part#267933058

Manufacturer:Stanley Black & Decker

UPC:662679330583

MFG #J7216H

Proto TorquePlus Socket, Standard Length, Yes Impact Rated, Measurement System: Imperial, Square Drive, 3/8 in Drive, 1/2 in Socket, 1-3/32 in Overall Length, 3/8 in Opening Depth, 3/4 in Drive End Width, 3/4 in Socket End Width, Side Locking Hole Locking, 6 Points, 19/32 in Bolt Clearance Depth, High Alloy Steel, Black Oxide

Specifications

Bolt Clearance Depth
19/32 in
Drive End Width
3/4 in
Drive Size
3/8 in
Drive Type
Square
Finish
Black Oxide
Impact Rated
Yes
Locking Type
Side Locking Hole
Material
High Alloy Steel
Measurement System
Imperial
Number of Points
6
Opening Depth
3/8 in
Overall Length
1-3/32 in
Socket End Width
3/4 in
Socket Size
1/2 in
Type
Standard Length

Application

For use on stubborn or damaged fasteners and also on fasteners made from soft materials

Item Features

  • The TorquePlus design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners
  • The TorquePlus configuration employs a radius corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage
  • The TorquePlus internal design minimizes fastener rounding, helps to extend fastener life and allows the user to more easily turn worn, rounded or rusted fasteners
  • Socket size stamped on tool for easy identification
  • Specially heat treated for the correct balance of strength and durability
  • Concentric openings
  • Large clearance holes
  • Tight nut end tolerances
  • Made from high alloy steel for greater strength
  • https://www.youtube.com/watch?v=JbPHzVaTH6M

Standards

ANSI B107.2|ASME B107.110-2012|Federal Specification GGG-W-660A

Documents

Catalog
Video Link
267933058

Proto TorquePlus J7216H Standard Length Socket, Imperial, 3/8 in Square Drive, 1/2 in

Description


Proto TorquePlus Socket, Standard Length, Yes Impact Rated, Measurement System: Imperial, Square Drive, 3/8 in Drive, 1/2 in Socket, 1-3/32 in Overall Length, 3/8 in Opening Depth, 3/4 in Drive End Width, 3/4 in Socket End Width, Side Locking Hole Locking, 6 Points, 19/32 in Bolt Clearance Depth, High Alloy Steel, Black Oxide

Product Number: 267933058

Manufacturer: Proto

Price:

$5.97 / EA

MFG #: J7216H

Manufacturer: Stanley Black & Decker

UPC: 662679330583

Specifications

Bolt Clearance Depth: 19/32 in

Drive End Width: 3/4 in

Drive Size: 3/8 in

Drive Type: Square

Finish: Black Oxide

Impact Rated: Yes

Locking Type: Side Locking Hole

Material: High Alloy Steel

Measurement System: Imperial

Number of Points: 6

Opening Depth: 3/8 in

Overall Length: 1-3/32 in

Socket End Width: 3/4 in

Socket Size: 1/2 in

Type: Standard Length

Standards

ANSI B107.2|ASME B107.110-2012|Federal Specification GGG-W-660A
